Rockbaby Golf Cart Golf Cartsuppliers
Product Introduction
Product parameters
| Model No. | TEG48B-02 (Ture 4 SEATS ) | ||
| Loading quantity | 19 pcs/ 40HQ | ||
| GENERAL SPECIFICATION | |||
| Battery | Lithium iron phosphate battery51.2V 105Ah | The following Picture just for your reference, your golf car will be subject to your choose. | |
| Motor | 48V AC 5KW Motor | ||
| Controller | 48V/400A AC Controller | ||
| Charger | Vehicle-mounted intelligent charger | ||
| Accelerator | Inductive 0-5V | ||
| Suspension | Front double cross arm independent suspension/Rear single arm + high strength spring shock absorption | Overall dimensions | 2995×1245×2040mm |
| Steering | Self Compensating" Rack & Pinion"Steering | Max. loading weight | 400KG |
| Brakes | Four Wheel Disc Brake and electronic parking | Net weight | 550KG |
| Passenger capacity | 4 | Chassis and frame： | Aluminium alloy |
| Driving Distance | 75 KM | Wheel base | 2050mm |
| Max. speed | 40KM/h | Front wheel tread | 990mm |
| Minimum turning radius | 3.6m | Rear wheel tread | 990mm |
| Max. climbing ability | 30% | Tires | Off-road 23*10-14 (Aluminium wheel) |
| Minimum ground clearance | 175mm | Braking distance | ≦5 |
| STANDARD CONFIGURATION | |||
| Windshield | Foldable Windshield (Anti-aging, anti-UV) with manual wiper | ||
| Dashboard | LCD 10.1 inch (MP3, MP4, reverse video) | ||
| Speaker | Professional grade long bar stereo | ||
| Body | PP+GF | ||
| Roof | PP | ||
| Mirror Supply | Left and right rearview mirrors with turning lights/in-car mirrors | ||
| Steering system | Self Compensating" Rack & Pinion"Steering | ||
| Brake system | Four Wheel Disc Brake and electronic parking | ||
| LED Light System | Front LED headlamp + running lamp + turn signal lamp+strip spotlight, rear brake lamp + running lamp | ||
| Steering Column | With combination switch (turn signal switch, horn switch and strip spotlight switch) | ||
| Accelerator | Adjustable Inductive Accelerator Continuously Variable Speed System | ||
| Seats | Leather fabric + high rebound PU seat + folding armrest | ||
| Rear axle | Integrated, Gear ratio12.31:1 | ||
| Storing space | Front built-in storage box and rear storage box | ||
| Power socket/output | 110V America standard socket | ||
| Starting | NFC card switch; Combination switch of steering and light; R/N/D/S knob gear, turn signal automatic return | ||
Company Advantages
· The unique golf cart design is close to the user’s aesthetic tastes.
· The excellent quality control throughout all stages of production ensures top quality of the product.
· With the potential development space, the economic effect of the product is highlighted.
Company Features
· As one of the leaders in the manufacture of golf cart, KANGYING INDUSTRY LIMITED today has the exclusive portfolio of products in the industry.
· Our company has achieved fruitful technical outcomes by cause of its strong technical base.
· Our goal is to establish a corporate culture that focuses particular attention on the quality that will make customers satisfied.
Application of the Product
Our golf cart is available in a wide range of applications.
KANGYING insists on providing customers with ELECTRIC SCOOTER,ELECTRIC POWER TOOLS of high quality and a one-stop solution that's comprehensive and efficient.
