Product Introduction
Product parameters
MODEL |
DB20 |
Type: |
110cc, Air cooled, 4-stroke, 1-cylinder |
Bore×Stroke: |
φ52.4*49.5mm |
Compression Ratio: |
8.8:1 |
Carburetor: |
PZ19 |
Ignition: |
CDI |
Starting: |
Electrical start |
Transmission: |
Automatic |
Drive Train: |
Chain drive |
Max. Power: |
4.7kw/8500r/min |
Max. Torque: |
6.5Nm/6500r/min |
Suspension/Front: |
Double shock absorber |
Suspension/Rear: |
Oil damper |
Brakes/Front: |
Hydraulic disc |
Brakes/Rear: |
Hydraulic disc |
Tires/Front: |
2.75-10 |
Tires/Rear: |
2.75-10 |
Overall Size (L*W*H) |
1370×630×840mm |
Seat Height: |
620mm |
Wheelbase: |
970mm |
Ground Clearance: |
160mm |
Battery: |
12V4Ah |
Fuel Capacity: |
4L |
Dry Weight: |
53kg |
Max. Load: |
70kg |
Package Size: |
1210×380×600mm |
Loading Quantity: |
78pcs/20´GP, 224 pcs/40´HQ |
Max. Speed: |
50km/h |
Starting Time: |
≤15s |
Company Advantages
· The design of Rockbaby electric bike supplier is performed by a professional design team who are specialized in designing for a long time.
· The product not only has passed the domestic quality standards but also has been approved by many international certificates.
· KANGYING INDUSTRY LIMITED is well-funded with adequate electric bike supplier supply and thoughtful service.
Company Features
· Rockbaby takes the lead in manufacturing high-quality electric bike supplier in the market.
· Occupying a large floor area, our factory not only has a complete set of production facilities that can guarantee stable productivity but also establishes a strict quality control system. This enables the factory to ensure stable products supply.
· We commit to an improved environment. We take all efforts to transform into a lean manufacturing way that aims to reduce wastes and pollution, so as to reduce our carbon footprint.
Application of the Product
Our electric bike supplier has been widely used in many industries.
We understand the actual situation of the market, and then combine the needs of customers. In this way, we develop the most suitable solutions for customers and effectively meet their needs.
