Product details of the dirt bike motorcycle
Product Overview
Rockbaby dirt bike motorcycle is manufactured adopting the latest technology and advanced technical equipment. Its service life is highly guaranteed by the strict test procedure. KANGYING INDUSTRY LIMITED strives to build a world-class integrated dirt bike motorcycle enterprise with global competitiveness.
Product Introduction
Next, KANGYING will show you dirt bike motorcycle's details.
Product Introduction
Product parameters
MODEL |
DB20 |
Type: |
110cc, Air cooled, 4-stroke, 1-cylinder |
Bore×Stroke: |
φ52.4*49.5mm |
Compression Ratio: |
8.8:1 |
Carburetor: |
PZ19 |
Ignition: |
CDI |
Starting: |
Electrical start |
Transmission: |
Automatic |
Drive Train: |
Chain drive |
Max. Power: |
4.7kw/8500r/min |
Max. Torque: |
6.5Nm/6500r/min |
Suspension/Front: |
Double shock absorber |
Suspension/Rear: |
Oil damper |
Brakes/Front: |
Hydraulic disc |
Brakes/Rear: |
Hydraulic disc |
Tires/Front: |
2.75-10 |
Tires/Rear: |
2.75-10 |
Overall Size (L*W*H) |
1370×630×840mm |
Seat Height: |
620mm |
Wheelbase: |
970mm |
Ground Clearance: |
160mm |
Battery: |
12V4Ah |
Fuel Capacity: |
4L |
Dry Weight: |
53kg |
Max. Load: |
70kg |
Package Size: |
1210×380×600mm |
Loading Quantity: |
78pcs/20´GP, 224 pcs/40´HQ |
Max. Speed: |
50km/h |
Starting Time: |
≤15s |
Company Introduction
Rockbaby is developed in its dirt bike motorcycle with high quality and professional service. Produced by the innovative machine, Rockbaby can guarantee the long service life of dirt bike motorcycle. Our high-quality products, including dirt bike motorcycle, will surely meet your expectations.
Look forward to working with you to create a better future.
